8.9 Programming at Installation
The Digital Nano / Nano+ requires the pool volume be programmed into the installer menu. The
Digital Nano / Nano+ will then indicate how many pounds (kgs) of salt to add should salt levels
fall.
1. Enter the “Installer menu” and program "Set pool volume" for specific pool. See "Calculating Pool
Volume" on page 34.
a.
Press MENU .
b.
Press △ or▽ until “Installer menu” is displayed.
c. Press and hold SELECT for 13 seconds to enter the “Installer menu”.
d.
Press △ or▽ until “Set pool volume” is displayed, then press SELECT.
l Factory setting is 15,000 gallons (60,000 liters).
l The range is 500 to 125,000 gallons (2,000 to 500,000 liters).
e.
Press △ or▽ until correct pool size is displayed; then press SELECT.
f.
Press △ or▽ until “End menu mode” is displayed, then press SELECT.
2. Configure the following as needed. See "Review Of Installer, Owner, & Maintenance Menu
Programming" on page 21.
l "Select language" (“English language”, “Idioma Español” “Langue Francaise” “Deutsche
Sprache”, “Lingua Italiana” or “Cesky Jazyk”)
l "Select units” (gallons / liters, lb / kg, ppm / mg/L)
l “Temperature units" (°F or °C)
l “Audio alarm” (On or Off)
l “Display temp” (“Hide temperature” or “Show temperature”)
3.
Press △ or▽ to adjust chlorine output to 50%.
SECTION 9 - TROUBLESHOOTING
9.1 Troubleshooting
Cell inspect due
Problem
This is an advisory message. The unit will generate chlorine normally while this message is
displayed.
Typical Solution
This is a reminder to remove and inspect the cell and filter screen to see if they need cleaning.
No problem has been detected. This is simply a time elapsed maintenance message. Press and
hold SELECT to clear this message.
Cell is cleaning
Problem
This is an advisory message.
Typical Solution
The cell is reversing polarity when this message is displayed. Normal production will resume
shortly.
