Fit CLOCKPLUS-IP to Talent Monitor
1. Remove the two screws that secure blanking plate and lift off the
plate.
2.
the talent monitor under the hinge.
X 2
X 2
1
2
3
3.
screw positions and then secure with the 2 x M3 countersunk screws
supplied.
Note!
camera number information.
Monitor Setup
To connect the ribbon cable: see Fit Talent Monitor to
EVO-IP Prompt Monitor on page 9
