14
Prompt Monitor Control Panel
WARNING! Risk of electric shock. Always disconnect
and isolate the product from the power supply before
attempting any servicing or removing the covers. Only
authorised technicians are permitted to service the display.
WARNING! DO NOT use if panel has been exposed
to water ingress, the panel has been dropped or the
enclosure is damaged. Refers to authorised service
personnel.
CAUTION! Personal Injury. Equipment Damage: Do not
place any objects on the cables. Route all cables such that
they do not present a stumbling hazard.
Connection
1.
power supply is disconnected.
Note! Incorrect connections may impair the proper function
2. 4-pin XLR,
12-16.8Vdc psu only.
(Use of any non authorised psu will invalidate the warranty).
OSD Controls (On Screen Display menu)
ENTER
Icon Function
ENTER
ENTER Button:
UP ARROW button:
RIGHT ARROW button:
Function Select / Flip Horizontal
DOWN ARROW button:
LEFT ARROW button:
Function Select / Flip Horizontal
TOGGLE button:
Toggles between Prompter / talent menu.
To range from the talent to prompt moniter, press the
toggle button twice, press again to return the OSD to
the talent monitor.
Monitor Conguration
To Next Page
