Monitor Conguration
OSD Menu
The following information describes how to navigate the main and
modify settings.
The individual function groups of the four main menu are selected
with the navigation button. The selected option is highlighted.
OSD Lock / Unlock
Lock OSD: Press the ENTER
ENTER
key once and then press the UP
key twice within 3 seconds when OSD is not active.
Unlock OSD: Press any key once, when “OSD Locked” appears on
the monitor, press the UP
key once followed by the right key
twice, within 3 seconds.
Main port
IP
SDI
*PIP Port
Expand
SDI
Main scaling
Expand
Aspect
1:1
Image rotation
Off
V Rotation
V Mirror
H Mirror
PIP mode
Small PIP
Large PIP
Off
Side by Side
PIP position
Top Right
Top Left
Bottom Right
Bottom Left
Auto scan
On
Off
simultaneously.
Port Settings
In the main menu input, select the input channel, input scan. PIP
mode, image rotation and scaling.
