26
Technical Specication
EPIC-IP
EPIC-IP15 EPIC-IP17 EPIC-IP19 EPIC-IP19XL
General
Operang temp. / Storage temp. 0° - +35°C / -20° - +60°C 0° - +35°C / -20° - +60°C 0° - +35°C / -20° - +60°C 0° - +35°C / -20° - +60°C
Weight 5.45kgs 6.25kg 7.05kgs 8.75kgs
Prompt Monitor Dimensions 400mm x 317mm x 41mm 440mm x 360mm x 41mm 468mm x 399mm x 41mm 467mm x 399mm x 41mm
Feedback Monitor Dimensions 400mm x 285mm x 19mm 440mm x 310mm x 19mm 468mm x 327mm x 19mm 596mm x 397mm x 22mm
Prompt Display
Size 15" 17" 19" 19"
Display Area 304mm x 228mm 338mm x 270mm 376mm x 301mm 376mm x 301mm
Brightness 1500 nits 1500 nits 1500 nits 1500 nits
Contrast 700:1 1000:1
Resoluon 1024x768 1280x1024
Viewing Angle 160° H / 120° V 170° H / 160° V
Feedback Display
Size 15.6" 17.3" 18.5" 24"
Display Area 344mm x 194mm 382mm x 215mm 409mm x 230mm 531mm x 299mm
Brightness 400 nits 350 nits 300 nits
Contrast 500:1 600:1 1000:1 5000:1
Resoluon 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080
Viewing Angle 140° H / 120° V 160° H / 140° V 178° H / 178° V
Ancillaries
Tally Display Std, 2 Front & 2 Side/Rear
Camera ID Opon, CLOCKPLUS-IP
Clock Display Opon, CLOCKPLUS-IP
