Autoscript EPIC-IP19XL - Prompt Monitor Connection Guide; Prompt Monitor Video Connection Options; 12 Vdc Power Input and Safety Precautions

17
Monitor Conguration
Connecting the Prompt Monitor
Video Connections

following options.


cable. The video cable screen should be connected to
earth (ground) at both ends.
Dual HD-SDI IN
Power Switch
Tally I/O
HD-SDI In Prompter Monitor
HD-SDI In Talent Monitor
CVBS In Talent Monitor
CVBS In Prompter Monitor
12Vdc 4-pin XLR
LAN RJ45
LTC
Dual CVBS IN
LTC Connection
Tally I/O Connection
Ethernet Connection
Power Switch

Technical Specications
Power In 12Vdc
WARNING! Always isolate the product from the power
supply before connecting the power supply lead.
Only use the supplied 4-pin XLR, 12-16.8Vdc PSU, use of

When all connections have been
made, attach the power supply
and press the power switch to
turn prompter on.
