19
Installation
1. Attach the cable tray if required, to the underside of the rail using
the 4 x 10mm M4 socket screws. Use the supplied Velcro cable
tie’s to secure cables to the tray.
Assemble the Rail and Carriage Assembly
S lide the arriage onto the ail.
1. Loosen the clamp lever (1) on the carriage assembly.
2.
carriage over the rail.
1
2
