EPIC-IP
EPIC-IP15 EPIC-IP17 EPIC-IP19 EPIC-IP19XL
Connecvity
Prompt Monitor Video Inputs
75Ω BNC type, HD-SDI BNC type, Pin: Centre: HD-SDI In. Outer: Ground (cable screen)
CVBS (PAL/NTSC) Pin: Centre: Composite Video In (PAL or NTSC). Outer: Ground (cable screen)
Feedback Monitor Video Inputs
75Ω BNC type, HD-SDI BNC type, Pin: Centre: HD-SDI In. Outer: Ground (cable screen)
CVBS (PAL/NTSC), Pin: Centre: Composite Video In (PAL or NTSC). Outer: Ground (cable screen)
Tally I/O
RJ12 socket, Power Switch Push-buon, latching
Pin1: +12Vdc Sensor in, Pin2: Sensor In, Pin3: N.C., Pin4: +12Vdc, Pin5: Sensor Out, Pin6: Ground
Timecode
BNC type, LTC (un-balanced)
VITC (via CVBS Prompt and Feedback Monitor Inputs), Opon
D-VITC (via HD-SDI Prompt and Feedback Monitor Inputs), Opon NTP (via LAN)
Pin: Centre LTC In, Outer: Ground (cable screen)
LAN RJ45, 10Base-T/100Base-TX
Power
Input 4-pin XLR, 12-16.8Vdc
Output 12Vdc (via Tally I/O)
Consumpon 42W 48W 51W 71W
Switch Pushbuon, latching
Pin Pin1: Ground (connected to monitor chassis), Pin4: +12Vdc
Technical specications are subject to change without notice.
Technical Specication
