Autoscript EPIC-IP19XL - EVO-IP General Specifications Overview; EVO-IP Display Specifications

28
EVO-IP
EVO-IP15 EVO-IP17 EVO-IP19
General
Operang temp. / Storage temp. 0° - +35°C / -20° - +60°C 0° - +35°C / -20° - +60°C 0° - +35°C / -20° - +60°C
Weight 3.0kgs 3.5kg 3.9kgs
Prompt Monitor Dimensions 400mm x 317mm x 41mm 440mm x 360mm x 41mm 468mm x 399mm x 41mm
Display
Size 15" 17" 19"
Display Area 304mm x 228mm 338mm x 270mm 376mm x 301mm
Brightness 1500 nits
Contrast 700:1 1000:1
Resoluon 1024x768 1280x1024
Viewing Angle 160° H / 120° V 170° H / 160° V
Ancillaries
Tally Display Std, 2 Front & 2 Side/Rear
Camera ID Opon, CLOCKPLUS-IP (or TALLYPLUS)
Clock Display Opon, CLOCKPLUS-IP
Connecvity
Prompt Monitor Video Inputs
75Ω BNC type, HD-SDI BNC type, Pin: Centre: HD-SDI In. Outer: Ground (cable screen)
CVBS (PAL/NTSC) Pin: Centre: Composite Video In (PAL or NTSC). Outer: Ground (cable screen)
Feedback Monitor Video Inputs
75Ω BNC type, HD-SDI BNC type, Pin: Centre: HD-SDI In. Outer: Ground (cable screen)
CVBS (PAL/NTSC), Pin: Centre: Composite Video In (PAL or NTSC). Outer: Ground (cable screen)
Tally I/O
RJ12 socket, (Opto-sensor/Contact closure/Digital Input/Digital Output) Pin1: +12Vdc Sensor In, Pin2: Sensor In,
Pin3: n.c., Pin4: +12Vdc, Pin5: Sensor Out, Pin6: GND. Power Switch: Push button latching.
Technical Specication
