Static Addressing Installation
Issue 3 April 2006 45
3. Enter the Gatekeeper IP address (H.323) or Registration Server IP address (SIP)
followed by the # button.
The following message displays:
where nnnnn is the value of the Management Complex (media server/gatekeeper)
transport-layer port number, a value between 0 and 65535.
4. Enter the appropriate value for the Port Number followed by the # button.
The following message displays:
where nnn.nnn.nnn.nnn is the value of the gateway/router IP address.
5. Enter the Gateway router IP address followed by the # button.
The following message displays:
where nnn.nnn.nnn.nnn is the value of the IP netmask.
6. Enter the IP netmask followed by the # button.
The following message displays:
where nnn.nnn.nnn.nnn is the value of the TFTP server IP address.
7. Enter the TFTP/HTTP Server IP address followed by the # button.
One of the following texts displays left-justified at the top of the display, depending on the
current status of 802.1Q:
8. Press the 1 or 0 button to turn 802.1Q on or off respectively.
The display is updated to show the current status of 802.1Q.
CallSvPort=nnnnn
New=_
Router=nnn.nnn.nnn.nnn
New=_
or nnn.nnn.nnn.nnn
Router=_
Mask=nnn.nnn.nnn.nnn
New=_
or nnn.nnn.nnn.nnn
Mask=_
FileSv=nnn.nnn.nnn.nnn
New=_
or nnn.nnn.nnn.nnn
FileSv=_
If 802.1Q is off: 802.1Q=off
1=on #=OK
If 802.1Q is on: 802.1Q=on
0=off #=OK
