Preparing Tools Needed for Mounting
Issue 1 May 2009 5
Avaya - Proprietary. Use pursuant to the terms of your signed agreement or Avaya policy.
DRAFT - January 25, 2009 - 1:38 PM
● Modem – in order to set up a remote configuration of the G430, you must prepare a USB modem.
Currently, the G430 supports the MultiTech USB modem, model MT5634ZBA-USB-V92.
Preparing Tools Needed for Mounting
To mount on a rack or wall, prepare a Phillips head screwdriver.
To mount on a wall prepare also:
● 415 x 465 mm (16.5 in. x 18.5 in.) plywood board 20 mm (7/8 in.) thick
● Wood screws
● Screws to fasten the G430 to the wall
You might also need wire cutters to attach the grounding conductors, if your site uses a ground block.
Choosing the Installation Site
Ensure that the location where you install your G430 fulfills the following requirements:
● Cables are away from sources of electrical noise such as radio transmitters, broadcast amplifiers,
power lines, fluorescent light fixtures
● Water or moisture cannot enter the case of the chassis.
● Air can flow freely around all sides of the chassis.
● The vents on the sides of the case are not blocked.
● The installation is no more than 25 feet (7.6 m) from an approved ground.
Note:
Note: If the G430 is more than 25 feet (7.6 m) away from an approved ground, you must contact a
licensed electrician to install a supplementary ground conductor.
● The environmental conditions match the following requirements:
● Ambient temperature – 32
o
to 104
o
F (0
o
to 40
o
C)
● Relative humidity – 10-90% relative humidity
● Minimum clearance for ventilation – 18 in. (45 cm)
● Weight support – 22.5-35 lbs (10-16 kg)
