Chapter 3: Mount the Devices
You can position the G430 – and EM200s, if ordered – on a suitable table, or mount them in a rack or on the
wall.The EM200s enable you to optionally extend the G430 by attaching one or two EM200 expansion
modules to the G430. Since the cables attaching the EM200 expansion modules to the G430 are short, you
must install the G430 and EM200s directly above or below each other, in any order.
Keep in mind the following:
● If you are mounting the G430 and EM200 module(s) on a wall, place them on a shelf affixed to the
wall, in addition to following all the wall mounting instructions.
● If you are mounting the G430 and EM200 module(s) on a table, affix the rubber legs to the
bottom-most unit, and place the other unit(s) directly on top.
● If you are mounting on a table or a wall, always place the G430 on top of the EM200(s). This enables
easy access in case you need to open the G430 cover in order to add or replace a DSP module or the
RAM board.
Note:
Note: Although the figures illustrating the mounting instructions depict a G430, all mounting
procedures apply equally to both the G430 and the EM200.
Positioning on a Table
To install a G430 or EM200 as a tabletop unit:
1. Remove the four rubber standoffs from their package.
2. Turn the device upside down.
3. Position each standoff into one of the mounting sites, near each corner of the chassis.
Mounting in a Rack
You can fasten the G430 or EM200 to a standard 19-inch rack either at the front of the device or at its
middle. Before you mount the device, attach the mounting brackets to the device.
Front Mounting Bracket Placement
Attach a regular mounting bracket to one side of the device, near the front, as shown in Figure 1: Front
mounting bracket placement on page 10. Attach a mounting bracket with cable guides to the other side of
the device, as shown in to Figure 3: Attaching a mounting bracket with cable guides
on page 10.
