Vendor Model Details
HP J9286B HP SFP+ direct attach copper cable — 33 feet (10
meters)
HP 487652–B21 HP Blade Systems C-Class SFP+ direct attach cable —
3.3 feet (1 meter)
HP 487655–B21 HP Blade Systems C-Class SFP+ direct attach cable —
10 feet (3 meters)
HP 487963–B21 HP Blade Systems C-Class SFP+ direct attach cable —
16 feet (5 meters)
If you use a verified third-party device, the
show interface gbic command output displays the
vendor SEEPROM data and the cable type.
Note:
The SEEPROM data output for third-party cables might be different than the model number.
Avaya devices are recommended to provide maximum compatibility and support for the VSP
7000 Series.
Related Links
SFP port LEDs on page 56
Installing SFP transceivers on page 57
SFP port LEDs
The switch front panel contains transmit (Tx) and receive (Rx) LEDs for each port. The following
table describes the SFP port LED status.
LED State Description
Tx Off No SFP or SFP+ transceiver
detected.
Emerald (Solid) SFP+ detected and link
established.
Emerald (Flashing) SFP+ link established and
transmitting.
Amber (Solid) SFP detected and link established.
Amber (Flashing) SFP link established and
transmitting.
Amber (Blinking) Tx and Rx blink slow, indicating
port is disabled.
Rx Off No SFP or SFP+ transceiver
detected.
Emerald (Solid) SFP+ detected and link
established.
Preparations for network connectivity
56 Installing Avaya VSP 7000 Series August 2014
