Country and plug
description
Specifications Typical plug
Australia
AS3112–1981 male plug
240 VAC
50 Hz
Single phase
Figure 5: Connecting AC power cord to the switch
Note:
Secondary power supply is optional for redundancy and load sharing.
Connecting AC power
Perform the following procedure to connect an AC power source to the switch.
Before you begin
To connect AC power to the switch an appropriate AC power cord is required. Ensure the
switch power supply supports AC power input.
About this task
Connecting the AC power source to the switch.
Power connections
VSP 7000 installation July 2013 23
