15
Item numbers in bold refer to the General Assembly drawing and Parts List on pages 18-19.
Servicing the Tool
Pressure Regulator and Filter Assembly
Air Pressure Indicator Assembly
• To remove the Pressure Regulator and Filter Assembly 45 from the cabinet, disconnect the two Air Hoses 59 and 63 at the
regulator.
• Remove the two screws, spacers, washers and nuts securing the regulator to the cabinet.
• Remove assembly from the cabinet.
• Replacement is in reverse order of removal.
• To remove the Air Pressure Indicator Assembly 53, remove the air hose from the rear of the gauge.
• Remove the clamp from the rear of the gauge and withdraw gauge from front of the cabinet.
• Replacement is in reverse order of removal.
• After any dismantling/assembling has occurred, the system MUST be primed.
IMPORTANT
The pressure regulator in the cabinet is set to 5.25 bar.
The pressure regulator must not be adjusted under any circumstances.
IMPORTANT
The safety valve in the cabinet is set to 5.25 - 5.30 bar.
The safety valve must not be adjusted under any circumstances.
