Avdel 07287 - Specifications; Tool Specification; Tool Dimensions

5
Dimensions shown in bold are in millimetres.
Other dimensions are in inches.
3000
118.11
07267
65
2.5
63 Ø
2.5 Ø
40 Ø
1.6 Ø
162
6.4
65
2.5
170
6.7
500
19.68
250
9.84
400
15.74
Air Pressure Minimum - Maximum 5-7 bar (72.5 - 101.5 psi)
Free Air Volume Required @ 5.5 bar (80 psi) 3.5 litres
Stroke Minimum Underload 29mm (1.14in)
Free Cycling 32mm (1.26in)
Pull Force @ 5.5 bar (80 psi) 32.4 kN
Cycle time Approximately 1.7 second
Noise Level 75 dB(A)
Pistol Weight (without nose equipment) 1.47 kg (3.23 lb)
Total Weight Pistol and Intensifier
(without nose equipment) 40 kg (88 lb)
Vibration Less than 2.5 m/s
2
(8.2 ft/s
2
)
Specifications
Tool Specification
Tool Dimensions
