3
Safety Rules 4
Specifications
Tool Specification 5
Tool Dimensions 5
Intent of Use
Tool Selection 6
Putting into Service
Air Supply 7
Operating Procedure 7
Nose Assemblies
Fitting Instructions 8
07287 Nose Assembly Components 8
Selection Tables for
Monobolt
®
, Avdelok
®
, Avtainer
®
, Maxlok
®
and Hemlok
®
9
Servicing Instructions 9
Accessories
Handle and Holster Kit 10
Side Ejector Adaptor 10
Stem Catcher Unit 10
Quick Connect Kit and Parts List 11
Servicing the Tool
Daily / Weekly 12
Moly Lithium Grease EP 3753 Safety Data 12
Service Kit 12
Maintenance 13
Stem Catcher Unit 13
Piston Assembly 13
Trigger Assembly 14
Cabinet 14
Push and Pull Intensifiers 14
Pressure Regulator and Filter Assembly 15
Air Pressure Indicator Assembly 15
Contents
LIMITED WARRANTY
Avdel makes the limited warranty that its products will be free of defects in workmanship and materials
which occur under normal operating conditions. This Limited Warranty is contingent upon: (1) the product
being installed, maintained and operated in accordance with product literature and instructions, and (2)
confirmation by Avdel of such defect, upon inspection and testing. Avdel makes the foregoing limited
warranty for a period of twelve (12) months following Avdel’s delivery of the product to the direct purchaser
from Avdel. In the event of any breach of the foregoing warranty, the sole remedy shall be to return the
defective Goods for replacement or refund for the purchase price at Avdel’s option. THE FOREGOING
EXPRESS LIMITED WARRANTY AND REMEDY ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES
AND REMEDIES. ANY IMPLIED WARRANTY AS TO QUALITY, FITNESS FOR PURPOSE, OR MERCHANTABILITY
ARE HEREBY SPECIFICALLY DISCLAIMED AND EXCLUDED BY AVDEL.
Avdel UK Limited policy is one of continuous product development and improvement and we reserve the right to change the specification of any product without prior notice.
General Assemblies
General Assembly of Handle and Parts List 16-17
General Assembly of Umbilical and Parts List 16-17
General Assembly of Cabinet and Parts List 18-19
General Assembly of Push Intensifier and Parts List 20
General Assembly of Pull Intensifier and Parts List 21
Priming
Oil Details 22
Hyspin
®
VG32 Oil Safety Data 22
Priming Procedure 23
Alternative Priming Procedure 24
Fault Diagnosis
Symptom, Possible Cause and Remedy 25
