Note: All the other signals are the same as the ones of the system disconnected, see previous table.
Note: each detector is self-disconnected after three alarms detected: the other detectors remain on.
Fully activated System
In this condition the control panel has different operations according to the chosen system configuration
( Traditional or Pre-Alarm, refer to Choice of the system configuration ) and programming performed upon
installation. Any detectors programmed with a delay, will create the alarms once the preset delay is
elapsed, during this time the control panel buzzer will emit an acoustic signal ( beep-beep-beep ).
24h tampering
In the event of control panel, detector or keypad tampering:
Acoustic signal emitted by the control panel internal sounder
Acoustic signal emitted by the AF53901R outdoor sounder
Enabling of outputs +SIR and +N
Panic
By enabling the panic alarm manually through the remote control or the keypad:
Acoustic signal emitted by the control panel internal sounder
3 minute-acoustic signal emitted by the AF53901R outdoor sounder
Enabling of outputs +SIR and +N
Enabling of PAN output for 15 seconds
Failure, Antiscanner
Supervision
In the event of an alarm:
Enabling of outputs +SIR and +N for 30 seconds
30 second- acoustic signal emitted by the control panel internal sounder
Enabling of ANOM output for 15 seconds
Traditional configuration Pre-alarm configuration
Pre-Alarm ... ... ...
In the event of an alarm due to a
detector belonging to a zone configured
as an external zone:
3 minute-acoustic signal emitted by
the control panel buzzer ( beep-beep-
beep ) interrupted during the call
3 minute-low intensity acoustic signal
emitted by the AF53901R outdoor
sounder
General alarm
In the event of a general alarm:
3 minute-acoustic signal emitted by
the control panel internal sounder
3 minute-acoustic signal emitted by
the AF53901R outdoor sounder
Enabling of outputs +SIR and +N
In the event of an alarm due to a
detector belonging to a zone not
configured as an external zone :
3 minute-acoustic signal emitted by
the control panel internal sounder
3 minute-acoustic signal emitted by
the AF53901R outdoor sounder
Enabling of outputs +SIR and +N
