TERMINAL BOARD DESCRIPTION
GND
Gnd
KEY
ON OFF input ( Closed towards gnd OFF )
IN1
Manual command input of vocal1 and sms1
message
GND
Gnd
IN2
Manual command input of vocal2 and sms2
message
TMPC
Tamper input zone C
IN3
Manual command input of vocal3 and sms3
message
C2
Wired alarm input C2
GND
Gnd
C1
Wired alarm input C1
IN4
Manual command input of vocal4 and sms4
message
TMPB
Tamper input zone B
IN5
Manual command input of vocal5 and sms5
message
B2
Wired alarm input B2
IN6
Manual command input of vocal6 and sms6
message
B1
Wired alarm input B1
GND
Gnd
TMPA
Tamper input zone A
PAN
Panic alarm output. Open collector, it closes
towards the negative 100mA/30Vdc
A2
Wired alarm input A2
RAP
Robbery alarm output. Open collector, it closes
towards the negative 100mA/30Vdc
A1
Wired alarm input A1
TEC
Technological alarm output. Open collector, it
closes towards the negative 100mA/30Vdc
GND
Gnd
ANOM
RF failure alarm output. Open collector, it closes
towards the negative 100mA/30Vdc
+N
Output for external sounder control ( lack off
positive with alarm on)
GND
Gnd
+SAA
External sounder power supply ( 14Vdc ).
With mains power ON, only
TC2
Open collector programmable output, it closes
towards the negative 100mA/30Vdc
+SIR
Internal sounder power supply ( 12Vdc
500mA )
With the control panel in alarm condition, only
COM
Output common contact 1A/125V (TC1)
GND
Gnd
NC
Output normally closed contact 1A/125V (TC1)
+OFF
System status output ( positive with the
control panel disactivated )
NO
Output normally open contact 1A/125V (TC1)
+ALI
Detectors power supply ( +12Vdc )
