75
+ Please make sure that the external IEEE 1394 HDD box you purchase at
your local electronic store should provide an external power adapter.
There are different types of IEEE1394 HDD box and hard disk from
different manufacturers, the power consumption has a varied range. If
the power of the external IEEE 1394 HDD is supplied from the USB of
this notebook, it may not run properly.
5.4 Using the External Audio System
At the right side of your computer, you will find the built-in audio ports. You
can connect Microphone jacks, earphone or a powered speaker.
To connect to an audio jack:
1. Locate the audio port (Microphone, Headphone) that you want to use to
the target device.
2. Plug the jack into the port on the right side of the system.
+ If you use external speakers and experience the sound distortion or
feedback, please lower the volume. Some factors are caused by locating
the microphone too close to the speakers. Moving the external audio
away option from the unit may also help.
5.5 Using the LAN Port
This notebook comes with an internal 10Base-T/100Base-TX LAN module
that connects your computer to other computers/networks through a local
area network (LAN) and supports data transfer rates at 10Mbps and can be
up to 100Mbps. The 10Base-T standard also called Twisted Pair Ethernet is
connected with RJ-45 connectors. The 100Base-TX is based on the older
