XR Series Installation and Technical Instructions 41

7.1 External Traffic Lights (XR 4500, XR 4500TL and XR 6500)

External traffic lights can be switched by the XR’s built-in relay.

1. Wire the traffic light to the traffic light terminal (J7) on the Controller

board. See Figure 7.1.

Figure 7.1 Traffic light terminal

See the pin assignments below:

Traffic Light Control

TRAFFIC LIGHT TO XR

HOT (+) COMMON

RED NEUTRAL (-) RED

GREEN NEUTRAL (-) GREEN
