44 XR Series Installation and Technical Instructions
XR Utility Programs
8.1 XR 4500, XR 4500TL, and XR 6500 Utility Programs
The XR remote display has several auxiliary functions that may be activated
via the OPTIONS dipswitches on the controller board.
Program 1: Normal Mode No specific program is selected.
Program 2: Axle Weighing
with Totals
Use this for axle scales only!
• Scale at zero – GREEN light.
• Truck drives its first axle on the scale, after motion stops – RED light.
The XR displays the axle weight and axle number (A1).
• GREEN light – Ready for the next axle. The next axle is driven onto the
scale. After motion stops – RED light. The XR displays the axle weight
and axle number (A2). Repeat for each remaining axle.
• After the last axle (weight at or near ZERO) – RED light. The truck’s
total axle weight is displayed for 10 seconds (flashing).
• Scale at or near ZERO – GREEN light. Ready for the next truck.
Program 3: Axle Weighing -
Driving On
Use this for axle weighing on regular vehicle scales.
• Scale at zero – GREEN light.
• Truck drives its first axle on the scale, after motion stops – RED light.
The XR displays and axle number (A1), then the axle weight – GREEN
light.
• The next axle is driven onto the scale. After motion stops – RED light.
The XR displays the axle number (A2), then the axle weight – GREEN
light.
• This is repeated until all axles are on the scale. After motion stops –
RED light. The XR displays the axle number (An), then the final axle
weight – GREEN light.
• If there is no motion or significant weight change for 12 seconds, the
truck’s total scale weight is displayed and the truck can drive off the
scale.
XR Utility Programs
PROGRAM SW 1 SW 2 SW 3 SW 4
1 – NORMAL Mode (No program) OFF OFF OFF OFF
2 – Axle Weighing with Totals OFF OFF ON OFF
3 – Axle Weighing (Driving On) OFF OFF OFF ON
4 – COMMAND mode OFF OFF ON ON
