16
English
Specifications
Camera
Lens 4.7-94mm, 20x zoom, F1.6 and automatic focus
Network
Network 100Base-TX
Cabling Type CAT5
Connector RJ-45
API ONVIF compliant (
www.onvif.org)
Security Password protection, HTTPS encryption, digest authentication, WS authentication,
user access log
Protocols IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP,
DHCP, Zeroconf, ARP
Streaming Protocols RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/
RTSP/HTTPS/TCP, HTTP
Mechanical
Dimensions ØxH 226 mm x 299.77mm, 8.9” x 11.8”
Weight 3.9 kg (8.6 lbs)
Dome Bubble Acrylic, clear
Body Aluminum
Housing Pendant mount
Finish Powder coat, cool gray 2
Tilt 186°, 0.05 - 360°/sec
Pan 360°, endless, 0.05 - 450°/sec
Presets 100 named presets
Tours 10 named guard tours
Electrical
Power Consumption 55 VA with AC power
44 W with DC power
25.5 W with IEEE 802.3at Class 4 PoE Plus
Power Source VAC: 24 V +/- 10%
VDC: 24 V, +/- 10%
PoE: IEEE 802.3at Class 4 PoE Plus compliant
Power Connector Waterproof 2-pin connector
Environmental
Operating Temperature -45 °C to + 50 °C (-50 °F to 122 °F) with external power
-30 °C to + 50 °C (-22 °F to 122 °F) with IEEE 802.3at Class 4 PoE Plus power
Storage Temperature -10 °C to +70 °C (14 °F to 158 °F)
Certifications
Safety UL 60950 CVV
CSA 60950 C-Tick
CB Scheme
Environmental IK09 Impact Rating Meets IP66 Weather Rating
Electromagnetic
Emissions
FCC Part 15 Subpart B Class B
IC ICES-003 Class B EN 55022 Class B
Electromagnetic
Immunity
EN 55024 Class B EN 61000-4-2 EN 61000-4-3
EN 61000-4-4 EN 61000-4-5 EN 61000-4-6
EN 61000-4-11
