Avision AD215 - Page 173

b
Wi-Fi Specifications:
Model: Module_WH_02
Main Chipset MediaTek MT7620
DDR2 SDRAM 64MB
SPI Flash 8MB
Standard Conformance IEEE 802.11b, IEEE 802.11g, IEEE
802.11n
Frequency Range 2.4 ~ 2.4835GHz
Modulation Technique DSSS with CCK, DQPSK, DBPSK
OFDM with BPSK, QPSK, 16QAM,
64QAM
Data Rate 802.11b: Up to 11Mbps
802.11g: Data Rate Up to 54Mbps
802.11n: Up tp 300Mbps
Transmit Power 20dBm(max)
Sensitivity 300M_2.4G:-70dBm
270M_2.4G:-70dBm
195M_2.4G:-71dBm
130M_2.4G:-74dBm
54M_2.4G:-79dBm
6M_2.4G:-94dBm
Antenna IPEX connector *2
