22 AutoView 1415/1515/2015 Switch Installer/User Guide
Figure 3.2: Setup Dialog Box (User)
Figure 3.3: Setup Dialog Box (Admin)
NOTE: Figure 3.3 displays for the Administrator if Local User Accounts are enabled, or for all user if Local User
Accounts are disabled.
Assigning server names
Use the Names dialog box to identify individual servers by name rather than by port number. The
Names list is always sorted by port order. Names are stored in the AVRIQ or IAC module, so even
if you move the module/cable to another ARI port, the name and configuration will be recognized
by the switch.
NOTE: If a server is turned off, its respective AVRIQ or IAC module will not appear in the Names list.
To access the Names dialog box:
1. Press
Print Screen to launch the OSCAR interface. The Main dialog box will appear.
2. Click Setup
- Names. The Names dialog box displays.
