4 AutoView 3050/3100/3200 Switch Installer/User Guide
Figure 2.1 illustrates a basic configuration for the AutoView 3100/3200 switch, using the
AutoView 3100/3200 model for the example. Descriptions follow in Table 2.1.
Figure 2.1: Basic AutoView 3100/3200 Switch Configuration (AutoView 3050 Switch Not Shown)
1
5
4
3
2
9
7
6
8
