Access the AutoView 3050/3100/3200 switch via a standard TCP/IP network
The Avocent AutoView 3050/3100/3200 switches provide agentless remote control and access. No
special software or drivers are required on the attached, or client, computers.
NOTE: The client connects to the AutoView 3050/3100/3200 switch using an Internet browser.
Figure 1.1: Example Switch Configuration (AutoView 3100/3200 shown)
Table 1.1: Descriptions for Figure 1.1
Number Description Number Description
1 UTP Connection 5 Ethernet
2 KVM Connection to the Switch 6 Digital User (Computer with Internet browser)
3 Remote IP Connection 7 Analog User (OSCAR
®
Graphical User Interface)
4 AutoView 3100/3200 Switch 8 Digital User (Computer with Internet browser)
