Chapter 3: Local Port Operation 17
Figure 3.1: OSCAR Interface Main Dialog Box
Managing a KVM session
Click Log Out to disconnect the KVM and user sessions.
-or-
Click Clear to
clear all offline IQ modules.
-or-
Click Disconnect t
o disconnect a KVM session.
Setup Dialog Box Functions
You can configure your AutoView 3050/3100/3200 switching system from the Setup dialog box
within the OSCAR interface. Select the Names button when initially setting up your AutoView
3050/3100/3200 switching system to identify target devices by unique names. Select the other
setup features to manage routine tasks for your target devices from the OSCAR interface menu.
Table 3.3: Main Dialog Box Functions
Button Function
Clear Clear all offline IQ modules.
Disconnect Disconnect the KVM session.
Setup Access the Setup dialog box and configure the OSCAR interface.
Commands Access the Commands dialog box.
