Table 3.7: Commands to Manage Routine Tasks for Your Target Devices
Features Purpose
Broadcast
Enable
Begin broadcasting to your target devices. Configure a target device list for broadcasting
under the Setup dialog box.
Scan Enable Begin scanning your target devices. Set up a target device list for scanning in the Setup
dialog box.
User Status View and disconnect users.
Display Versions View version information for the DSR switch as well as view and upgrade firmware for
individual DSRIQ modules.
Reset PS/2 Re-establish operation of PS/2 keyboard and mouse.
Chapter 3: Local Port Operation 35
To access the OSCAR interface Commands dialog box:
1. If the OSCAR interface is not open, press Print Screen to open the Main dialog box.
2. Click Commands to open the Commands dialog box shown in Figure 3.16.
Figure 3.16: OSCAR Interface Commands Dialog Box
Viewing and disconnecting user connections
You can view and disconnect users through the User Status dialog box. The username (U) will
always be displayed; however, you can display either the target device name or EID number to
which a user is connected. If there is no user currently connected to a channel, the user field will be
blank and the Server Name field will display Free.
To view current user connections:
1. If the OSCAR interface is not open, press Print Screen to open the Main dialog box.
