Appendices 85
Appendix F: Technical Specifications
Table F.1: DSR1020/2020/4020/8020 Switch Product Specifications
Server Ports
Number 16
Type PS/2, Sun, USB and Serial
Connectors 8-pin modular
Sync Types Separate horizontal and vertical
Plug and Play DDC2B
Video Resolution
640 x 480 @ 60 Hz
800 x 600 @ 75 Hz
960 x 700 @ 75 Hz
1024 x 768 @ 75 Hz
1280 x 1024 @ 75 Hz
Supported Cabling 4-pair UTP CAT 5 or CAT 6, 10 meters maximum length
Dimensions
Form Factor 1-U rack mountable
Height x Width x Depth
1.72 x 17.00 x 10.98 in
(4.37 x 43.18 x 27.98 cm)
Weight (without cables) 7.3 lbs (3.31 kg)
SETUP Port
Number 1
Type RS-232 serial
Connector DB9 male
Network Connection
Number 1
Type 10/100/1000 Ethernet
Connector 8-pin modular
Local Port
Number 1
