UNPACKING
This chapter provides details about the contents of a complete product package, along with instructions on how
to safely unpack the product and, if needed, initiate a product return.
Package Contents
The following tables contains an overview of the package contents of the Product.
No. Quantity Description Avonic SKU
1 1 pc PTZ Camera AV-CM93-NDI-B/W
2 1 pc Remote Control AV-CM40-RC
3 1 pc USB cable type A to type B AV-USB20-AB
4 1 pc Power Adapter 12V/A (GME Technology (Shenzhen) Co., ltd ,
model number: GME24A - 120200FDS2)
AV-CM40-PSU
5 1 pc RS-232 9-pin D-Sub female to DIN -8 male AV-CM-RS-232
6 1 pc 5-way Phoenix Balanced audio con. (CTBP92HE/5) AV-PHNX-5
7 1 pc 2-way Phoenix RS-485 connector AV-PHNX-2
Each item is visualized below and referenced by the associated number in the table above:
Figure 3: Package Contents
Power Adapter Usage
Note
: * Use only the Power Adapter of GME Technology (Shenzhen) Co., ltd with model number: GME24A -
120200FDS2 in combination with the CM93 camera. Using another Power Adapter may lead to injury and/
or damage to the product. See the picture of the Power Adapter label at the left:
Figure 4: Power Adapter label
17
