APPENDIX 1 SPECIFICATIONS
48
Model 1 Model 2 Model 3
Mobile Surveillance YES
Picture Zoom 2X digital zoom
PTZ Control YES
Alarm I/O 16 inputs, 1 output
Key Lock (Password Protection) YES
Local User Level Administrator & Operator
Video Loss Detection YES
Camera Title Supports up to 12 letters
Video Adjustable Hue / Saturation / Contrast / Brightness
Date Display Format YY/MM/DD, DD/MM/YY & MM/DD/YY
Daylight Saving YES
Power Source (±10%) DC 19V
Power Consumption (±10%) < 64 W
Operating Temperature 10 ~ 40 (50 ~104 )℃℃℉℉
Dimensions (mm)***
430(W) x 65(H) x
338(D)
432(W) × 90(H) × 326(D)
System Recovery System auto recovery after power failure
Optional Peripherals Keyboard controller
* The specifications are subject to change without notice.
** 1 HDD capacity up to 2TB
*** Dimensional Tolerance: ±5mm
