APPENDIX 1 SPECIFICATIONS
49
 For 8CH Models
Model 4 Model 5 Model 6
Video System NTSC / PAL (auto detection)
Video Compression Format H.264
Video Input
(composite video signal 1 Vp-p 75Ω BNC)
8 channels
Video Loop Output
(composite video signal 1 Vp-p 75Ω BNC)
-- 8 channels
Video Output (BNC) Main Monitor For stable display
Call Monitor -- For sequence display
Video Output (VGA) Built-in (Resolution support up to 1600 x 1200)
Audio Input / Output 4 audio inputs / 1 audio output (Mono)
4 audio inputs / 2
audio outputs (Mono)
Maximum Recording Rate Frame
704×480 pixels with 120 IPS <NTSC> / 704×576 pixels with 100 IPS <PAL>
Field
--
704x240 pixels with 240 IP
S
<NTSC> /
704×288 pixels with 200
IPS <PAL>
CIF
352×240 pixels with 480 IPS <NTSC> / 352×288 pixels with 400 IPS <PAL>
Image Quality Setting SUPER BEST / BEST / HIGH /NORMAL
Hard Disk Storage** Accommodates 2 SATA HDDs
Quick Search Time / Motion / Alarm search mode
SATA Interface Built-in
Recording Mode Manual / Timer / Motion / Alarm / Remote
Multiplex Operation Live display / record / playback / backup / network operations
USB Mouse Control YES
Motion Detection Area 16 × 12 grids per camera for all channels
Motion Detection Sensitivity 3 adjustable parameters for accurate detection
Pre-alarm Recording YES
Backup Device USB 2.0 flash drive / Network
DVD Writer
(Optional) / Flash
drive / Network
Web Transmitting Compression Format H.264
Ethernet 10/100 Base-T. Supports remote control and live view via Ethernet
Supports licensed software “Video Viewer” /
Internet Explorer, Mozilla Firefox, Safari & Google Chrome
web browsers / QuickTime player
Web Interface
*Operating System: Windows 7 / Vista / XP / 2000
Max. Online User 5 10
Network Protocol TCP/IP, PPPOE, DHCP and DDNS
Remote Independent Operation YES
Remote Live Audio NO YES
Remote Event Download & Playback YES
Event Notification By FTP / E-Mail
IR Remote Control YES (IR receiver built-in)
Mobile Surveillance YES
Picture Zoom 2X digital zoom
PTZ Control YES
Alarm I/O 8 inputs, 1 output

Avtech MDR688ZB Specifications

General

Brand	Avtech
Model	MDR688ZB
Category	DVR
Language	English
