AWA E-6880 - HOW TO REPLACE THE STYLUS (NEEDLE); Stylus Replacement Procedure

11

HOWTOREPLACETHESTYLUS(NEEDLE)


Caution:

Checkthestylustoseeifitisinthemiddlecenter.
NOTE:Followthirdphotowhichiscorrect.













• Donotremoveorbendthestylus.
• Donottouchtheneedleasitcouldinjureyourhand.
• Don’t let the stylus
touch the turning turntable when there is no
record.
• Turnofftheunit'spowerbef oreyoureplacethestylus.

Removingoldstylus
1. Set a screwdriver at the tip of the stylus and push
downinthedirection“A”.
2.Removethestylusbypullingitforwardanddown.

Installinganewstylus
1.Holdthetipofthestylusandinserttheotheredgeby
pressinginthedirection“B”.
2.Pushupthedirection“C”untilitlocksatthetip.
