Awoco SP-06 - Default Chapter; Table of Contents

3
Table of Contents
Important Safety Instructions 4
How to Test Run 5
Step 1a. If the Awoco Split Hood Unit or the Control Unit is purchased 5
Step 1b. If the Awoco Split Hood Unit or the Control Unit is NOT purchased 6
Step 1c. Connect the Blower Unit to the Control Panel on the Existing Range Hood 7
Step 2 7
Installation 8
Installing the Blower Unit 8
Control Unit Buttons & Functions 9
Troubleshooting 10
Warranty 11
Caution
DO NOT
connect the Power Cord's Black, White and Green wires directly to Blower Unit's Black, White and
Green wires. Incorrect wire connections will cause damage to the motor, which is
NOT COVERED
in the
warranty.
• The
Green
- Speed 2 wire from the Blower Unit
IS NOT
a
Ground
wire.
• The White - Speed Q wire from the Blower Unit
IS NOT
a
Neutral
wire.
• The
Black
- Neutral wire from the Blower Unit
IS NOT
a
Hot
wire.
Speed
3
Speed
2
Speed
1
Speed
Q
Neutral
NeutralGround Hot
