| INTRODUCTION
7
TECH SPECS MACROTEL X1 - MACROTEL X2
General Features
Macrotel X1
Macrotel X2
End User / Price List
799 €
1.085 €
Lines
1 Pots/Pstn Line or
1 Gsm Line (by option)
2 Pots lines or
2 GSM lines(by option) or
1 Pots line + 1 GSM line (by option)
Phone Line
1x RJ11 6/4
2x RJ11 6/4
Set Line
1x RJ11 6/4
2x RJ11 6/4
GSM Line
1x RJ10
2x RJ10
Line Mode
Standard 2-Wire connection or GSM(by option)
Telephone Set mode
Worldwide mode, software setup
Audio Features
Audio process
24Bit-120Mhz DSP-Based audio process
A.G.C
Fixed - 1 stage
Ducking
No
No
Echo canceller
Yes
Yes
De-Noiser
No
No
Attenuator
Yes
Yes
2-Band EQ
Yes
Yes
Tone generator
0 dBu @ 800 Hz
0 dBu @ 800 Hz
Dialer keypad Software
Yes
Yes
DTMF Decoder
No
No
Conference Mode
No
Yes
Auto call Hook/Drop
Yes
Yes
Front Panel operation
Hook / drop push button
Yes, separate Hook and Drop
Yes, same button for Hook and Drop
Ring light
Hook-1 push button
Hook-1 & Hook-2 push button
LCD Panel
160x32p LCD graphic display
Level Send & receive
Showed in LCD graphic display
Audio Input and Output
Send Analog-1
1x XLR female electronically balanced
1x XLR female electronically balanced
Send Digital-1
No
No
Receive Analog-1
1x XLR male electronically balanced
1x XLR male electronically balanced
Receive Digital-1
No
No
Send Analog-2
1x XLR female electronically balanced
1x XLR female electronically balanced
Send Digital-2
No
No
Receive Analog-2
1x XLR male electronically balanced
1x XLR male electronically balanced
Receive Digital-2
No
No
Microphone Input
Software switch Mic/Line
Remote Control
GPIO Connector
SubD 15p HD
GPIO Type
4x GP In optocoupled, 4x GP Out Open Collector optoisolated
USB
1x USB – B Type EMI Filtered
Serial
2x Rs232 EMI Filtered
Software Remoter
Yes
GSM Wireless module
by option
Ethernet Port /Web Server
No
Parser ASCII protocol
No
