Axis 211M User Manual

AXIS 211M - Using the Network Camera
10
AMC audio controls
There are audio controls for controlling the client computer’s speaker output. These controls are only available
when audio is enabled, see
AXIS Media Control (AMC), on page 12 and Audio Settings, on page 17.
Click the Speaker and Microphone buttons to switch the sound off and on for the speaker and
microphone, respectively.
Use the sliders to control the volume on the speaker and microphone. The volume can be set
between 0 and 100.
When using Half-duplex mode, this button toggles between allowing you to speak and listen. The
first icon indicates that you can talk and the speaker attached to the camera will play your voice.
The second indicates that you will hear audio from the camera, but no audio will be sent to any web
clients.
When in Simplex talk mode, the icon toggles between allowing you to speak and is dimmed when
you do not want other clients to receive any audio.

Axis 211M Specifications

General

Maximum resolution	1280 x 1024 pixels
Camera shutter speed	1/15000 - 1/4 s
Minimum illumination	1 lx
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/3 \
Focal length range	3 - 8 mm
Power source type	PoE
Power consumption (typical)	5 W
Processor model	ARTPEC-A
Flash memory	8 MB
Internal memory	64 MB
I/O ports	1x RJ-45
Dimensions (WxDxH)	44 x 88 x 172 mm
Power requirements	DC 7 - 20V
Resolution description	1.3MP
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	244 g
