Axis 211M User Manual

AXIS 211M - Product Features
5
Overview
External microphone/line in - One 3.5mm input for a mono microphone, or for line in mono signal (only the
left channel is used from a stereo signal).
Power indicator
Network indicator
Control button
Serial number
Mounting
screw hole
Rear panel
External microphone/
line in
Power connector
Audio output
line out
I/O terminal connector
Network connector
(and PoE)
DC-Iris
Focus puller
Tele/wide puller
Status indicator
& Microphone
Underside
DC-Iris
control cable

Axis 211M Specifications

General

Maximum resolution	1280 x 1024 pixels
Camera shutter speed	1/15000 - 1/4 s
Minimum illumination	1 lx
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/3 \
Focal length range	3 - 8 mm
Power source type	PoE
Power consumption (typical)	5 W
Processor model	ARTPEC-A
Flash memory	8 MB
Internal memory	64 MB
I/O ports	1x RJ-45
Dimensions (WxDxH)	44 x 88 x 172 mm
Power requirements	DC 7 - 20V
Resolution description	1.3MP
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	244 g
