AXIS 211M - Technical Specifications
43
Technical Specifications
Item Specification
Image sensor 1/3” Micron Progressive Scan RGB CMOS 1.3 Megapixel
Lens 3.0 - 8.0 mm, F1.0, DC-iris, CS mount.
Horizontal viewing angle: 35º-93°,
Minimum
illumination
1lux, F1.0
Video compression • Motion JPEG
• MPEG-4 Part 2 (ISO/IEC 14496-2) with motion estimation, Profiles: Advanced Simple Profile level 0-5 and Simple
Profile level 0-3
Resolutions 24 resolutions from 1280 x 1024 to 160 x 90 via API,
22 selections via configuration web page
Frame rate Motion JPEG:
• Up to 12 fps in 1280 x 1024
• Up to 20 fps at 1024 x 768 (partial scan)
• Up to 30 fps at 800 x 600 (partial scan)
MPEG-4:
• Up to 8 fps at 1280 x 1024
• Up to 13 fps at 1024 x 768 (partial scan)
• Up to 20 fps at 800 x 600 (partial scan)
*Partial scan takes the data from the center region of the sensor and then scales it down to present an image at optimal
frame rate.
Video streaming • Simultaneous Motion JPEG and MPEG-4
• Controllable frame rate and bandwidth
• Constant and variable bit rate (MPEG-4)
Image settings • Compression levels: 100
• Rotation: 0º, 180º
• Configurable color level, brightness, sharpness, contrast, white balance, exposure control
• Mirroring
• Overlay capabilities: time, date, text, image or privacy mask
Shutter time 1/4 to 1/15000 sec.
Audio • Two-way (full and half duplex) or one-way or audio off.
• Built-in microphone and external microphone input or line input. Mono audio output (line level) connects to
active speaker with built-in amplifier.
• Audio compression: G.711 PCM 64kbit/s, G.726 ADPCM 32 or 24 kbit/s, AAC LC 8-32kbit/s+R17
Security • Multiple user access levels with password protection, IP address filtering, HTTPS encryption,
Network control IEEE 802.1x
• Digest authentication
Users • 20 simultaneous users
• Unlimited number of users using multicast (MPEG-4)
Alarm and event
management
• Events triggered by built-in motion detection, audio detection, external input or according to a schedule.
• Image upload over FTP, email and HTTP. Notification over TCP, email, HTTP and external outputs.
• Pre- and post alarm buffer: up to 20 MB (250 images or more, in full 1280 x 1024 resolution in Motion JPEG)
Connectors • RJ-45 for Ethernet 10BaseT/100BaseTX, Auto-MDIX
• Terminal block for 1 alarm input, 1 output and alternative power connection
• 3.5 mm jack for Mic or Line mono input
• 3.5 mm jack for Line mono output.
Casing Plastic
Processors, memory,
clock
• CPU, video processing and compression: ARTPEC-A
• RAM: 64 MB
• Flash: 8 MB
• Battery backed-up real-time clock
Power 7-20 V DC max 5 W
PoE IEEE802.3af Class 2
Operating conditions 0 - 45 ºC (32 – 113 ºF)
Humidity 20 - 80% RH
