Axis 211M User Manual

AXIS 211M - Technical Specifications
44
Installation,
management and
maintenance
AXIS Camera Management tool on CD and web-based configuration
Configuration of backup and restore
Firmware upgrades over HTTP or FTP, firmware available at www.axis.com
Video access from
Web browser
Camera live view, Video recording to file (ASF), Sequence tour for up to 20 Axis video sources
Customizable HTML pages
Minimum
requirements
Pentium III CPU 500 MHz or higher, or equivalent AMD,128 MB RAM, AGP graphics card 32 MB RAM, Direct Draw
Windows 2000 or later Internet Explorer 6.x or later
For other operating systems and browsers see www.axis.com/techsup
System integration
support
Open API for application integration including AXIS VAPIX API*, AXIS Media Control SDK*, event trigger data in video
stream
Quality of Service (QoS) Layer 3, DiffServ Model
Embedded Linux operating system
* Available at www.axis.com
Supported protocols IPv4/v6, HTTP, HTTPS, SSL/TLS*, TCP, QoS, SNMPv1/v2c/v3 (MIB-II), RTSP, RTP, UDP, IGMP, RTCP, SMTP, FTP, ICMP DHCP,
UPnP, Bonjour, ARP, DNS, DynDNS, SOCKS, IEEE802.1X. More information on protocol usage available at www.axis.com
*This product includes software developed by the Open SSL Project for use in the Open SSL Tool kit (www.openssl.org)
Video management
software
(not included)
AXIS Camera Station - Surveillance application for viewing, recording and archiving up to 25 cameras
See www.axis.com/partner/adp_partners.htm for more software applications via partners
Accessories
(included)
Power supply 9 V DC,
stand,
connector kit,
Installation Guide,
CD with installation tool, software and User’s Manual,
MPEG-4 licenses (1 encoder, 1 decoder),
MPEG-4 decoder (Windows)
Accessories
(not included)
Housings for adverse indoor/outdoor environments
Power over Ethernet midspans
AXIS 292 Network Video Decoder
MPEG-4 Decoder multi-user license pack
Approvals EN 55022 Class B,
EN 61000-3-2,
EN 61000-3-3,
EN 55024,
FCC Part 15 Subpart B Class B,
ICES-003 Class B
VCCI Class B,
C-tick AS/NZS CISPR22,
EN 60950-1
Power supply: EN 60950, UL, cUL
Dimensions (HxWxD)
and weight
44 x 88 x 172 mm (1.7” x 3.5” x 6.8”)
244 g (0.5 lb) excl. power supply
Item Specification

Axis 211M Specifications

General

Maximum resolution	1280 x 1024 pixels
Camera shutter speed	1/15000 - 1/4 s
Minimum illumination	1 lx
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/3 \
Focal length range	3 - 8 mm
Power source type	PoE
Power consumption (typical)	5 W
Processor model	ARTPEC-A
Flash memory	8 MB
Internal memory	64 MB
I/O ports	1x RJ-45
Dimensions (WxDxH)	44 x 88 x 172 mm
Power requirements	DC 7 - 20V
Resolution description	1.3MP
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	244 g
