AXIS 211M - Video and Image settings
15
Overlay/Mask Settings
Overlay/Mask Type
The following options are available for overlays and masks:
• Uploaded image as overlay
• Configurable areas as privacy mask
Uploaded image as overlay is a text and/or a static image superimposed over the video image, for extra
information.
To upload an overlay image to the camera:
1. Select the type of overlay to use in Overlay/Mask Type.
2. In the field Upload own image, click the Browse button and locate the image file on your computer or
server.
3. Click the Upload button and follow the on-screen instructions.
To use an already uploaded image:
1. Select an uploaded image from the Use image drop-down list.
2. Place the image at the required location by entering the x and y coordinates.
3. Click Save.
Overlay image requirements
There are a number of limitations when using overlay images, such as the size and positioning of images. Please
refer to the online help for more information.
Configurable areas as privacy mask are configurable areas of solid color that can be used to block out certain
parts of the video image.
Note: Make sure to set privacy masks while camera is set for full resolution to ensure full coverage of sensitive area.
Advanced - Camera Settings
This page contains settings for fine-tuning the video image. These include the color level, brightness, sharpness
and exposure control. DC-Iris should always be enabled, except when focusing, or when using a non-DC-Iris
lens.
Please see the online help for further information on these settings.
Low Light Behavior
Exposure priority - These settings define the balance between possible motion blur, noise and frame rate.
Prioritize Image Quality to lower noise may reduce frame rate while increasing exposure time and thereby
motion blur. A prioritized frame rate limits the exposure time in order to allow for full frame rate. This may raise
the gain factor, creating possible noise or darker exposure.
Image Formats Image Size
• Windows 24-bit BMP (full color) The height and width of the overlay image in
pixels must be exactly divisible by 4.
• Windows 4-bit BMP (16 colors) The height and width of the overlay image in
pixels must be exactly divisible by 16.

Axis 211M Specifications

General

Maximum resolution	1280 x 1024 pixels
Camera shutter speed	1/15000 - 1/4 s
Minimum illumination	1 lx
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/3 \
Focal length range	3 - 8 mm
Power source type	PoE
Power consumption (typical)	5 W
Processor model	ARTPEC-A
Flash memory	8 MB
Internal memory	64 MB
I/O ports	1x RJ-45
Dimensions (WxDxH)	44 x 88 x 172 mm
Power requirements	DC 7 - 20V
Resolution description	1.3MP
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	244 g
