Axis A1601 Installation Guide

AXISA1601NetworkDoorController
6–pinterminalblock
FunctionPinNotes
Specications
DCground
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDC
Maxload=50mAfor
eachI/O
Digitalinput–Connecttopin1toactivate,or
leaveoating(unconnected)todeactivate.
0tomax30VDC Congurable
(Inputor
Output)
3–
6
Digitaloutput–Internallyconnectedtopin1(DC
ground)whenactive,andoating(unconnected)
wheninactive.Ifusedwithaninductiveload,
e.g.,arelay,connectadiodeinparallelwiththe
load,toprotectagainstvoltagetransients.Each
I/Oiscapableofdriving12VDC,50mA(max)
externalload,ifinternal12VDCoutput(pin2)is
used.Inthecaseofusingopendrainconnections
incombinationwithanexternalpowersupply,
thentheI/OscanmanageDCsupplyof0–30V
DC,100mA.
0tomax30VDC,
opendrain,100mA
1
DCground
2
DCoutput12V
3
I/Oconguredasinput
4
I/Oconguredasoutput
5
CongurableI/O
25

Axis A1601 Specifications

General

Operating System	Linux
Power	12-24 V DC
Protocols	IPv4, IPv6, SNMPv1/v2c/v3, UPnP
USB Ports	USB 2.0
Serial Ports	RS-485/RS-422
