Axis M3203 Installation Guide

AXIS M32 Series Installation Guide Page 3
ENGLISH
AXIS M32 Series Installation Guide
This installation guide provides instructions for installing the AXIS M32 Series on your network. For
all other aspects of using the product, please see the User’s Manual, available on the CD included in
this package, or from www.axis.com/techsup
Installation steps
1. Check the package contents against the list below.
2. Hardware overview. See page 4.
3. Install the hardware. See page 6.
4. Assign an IP address. See page 7.
5. Set the password. See page 10.
6. Adjust the focus. See page 12.
7. Complete the installation. See page 12.
Package contents
Item Models/variants/notes
Network camera AXIS M3203 - Tamper-resistant Network Camera
AXIS M3203-V - Vandal-resistant Network Camera
AXIS M3204 - Tamper-resistant Network Camera
AXIS M3204-V - Vandal-resistant Network Camera
Mounting kit Screwdriver for tamper-proof screws
2 tamper-proof screws (M4x16 Resitorx)
Drill template
CD AXIS Network Video Product CD, including product documentation,
installation tools and other software
Printed Materials AXIS M32 Series Installation Guide (this document)
Axis Warranty Document, AVHS Authentication key
Important!
This product must be used in
compliance with local laws and
regulations.

Axis M3203 Specifications

General

Maximum resolution	800 x 600 pixels
Video formats supported	H.264
Pan range	0 - 360 °
Tilt angle range	0 - 170 °
Angle of rotation	340 °
Camera shutter speed	1/24500 - 1/6 s
Minimum illumination	0.9 lx
Focal length range	2.8 - 10 mm
Video motion detection	Yes
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Power source type	PoE
Ethernet LAN (RJ-45) ports	1
Dimensions (WxDxH)	140 x 132 x 94 mm
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, EN 60950-1, KCC Class B
Processor model	ARTPEC-3
Flash memory	128 MB
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	85258900

Weight and Dimensions

Weight	430 g
