AXISM32DomeCameraSeries
Specifications
•Ensuringthecameraislevel.Pressthebuttonfornotmorethantwosecondstostartthelevelingassistantandpress
againtostop.ThestatusLEDandbuzzersignal(see)assistlevelingofthecamera.Thecameraislevelwhenthebuzzer
beepscontinuously.
•Ensuringthecameraislevel.Pressthebuttonfornotmorethantwosecondstostartthelevelingassistantandpressagain
tostop.Thebuzzersignal(see)assistlevelingofthecamera.Thecameraislevelwhenthebuzzerbeepscontinuously.
•ConnectingtoanAXISVideoHostingSystemservice.Toconnect,pressandholdthebuttonforabout3secondsuntilthe
statusLEDashesgreen.
•Connectingtoaone-clickcloudconnection(O3C)serviceovertheinternet.Toconnect,pressandholdthebutton
forabout3secondsuntilthestatusLEDashesgreen.
Connectors
Networkconnector
TheAxisdeviceisavailableintwovariantswithdifferentnetworkconnectors:
RJ45Ethernetconnector.
RJ45EthernetconnectorwithPoweroverEthernet(PoE).
RJ45EthernetconnectorwithPoweroverEthernetPlus(PoE+).
RJ45withHighPoweroverEthernet(HighPoE).
RJ45Push-pullConnector(IP66)withHighPoweroverEthernet(HighPoE).
RJ45Ethernetserviceport.
D-codedM12connectorwithPoweroverEthernet(PoE).
SFPconnector.
NO NO
NO
TICE TICE
TICE
TocomplywiththeIP66-rateddesignofthecameraandmaintaintheIP66protection,thesuppliedRJ45Push-pullConnector
(IP66)shallbeused.Alternatively,usetheRJ45IP66-ratedcablewithpremountedconnectorwhichisavailablefromyour
Axisreseller.Don’tremovetheplasticnetworkconnectorshieldfromthecamera.
Audioconnector
3.5mmconnector
•Audioin–3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelisusedfromastereosignal).
•Audioin–3.5mminputforadigitalmicrophone,ananalogmonomicrophone,oraline-inmonosignal(leftchannelis
usedfromastereosignal).
•Audioin–3.5mminputfortwomonomicrophones,ortwoline-inmonosignals(usingthesuppliedstereo-to-mono
adapter).
•Audioin–3.5mminputforastereomicrophone,oraline-instereosignal.
•Audioout–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoranactive
speakerwithabuilt-inamplier.Astereoconnectormustbeusedforaudioout.
•Audioout–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoranactivespeaker
withbalancedinputandabuilt-inamplier.Abalancedconnectormustbeusedforaudioout.
•Audioout–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoranactivespeaker
withabuilt-inamplier.Apairofheadphonescanalsobeattached.Astereoconnectormustbeusedforaudioout.
63
