AXIS M7001 - Technical Specifications
Technical Specifications
Item Specification
Video compression • H.264
• Motion JPEG
Resolutions NTSC: 720x480 to 176x120
PAL: 720x576 to 176x144
Frame rate H.264 30/25 (NTSC/PAL) fps in all resolutions
Frame rate Motion
JPEG
30/25 (NTSC/PAL) fps in all resolutions
Video streaming • Simultaneous H.264 and Motion JPEG streams in maximum resolution at 30/25 fps
• Controllable frame rate and bandwidth
• VBR/CBR H.264
Image settings • Compression, color, brightness, contrast
• Rotation: 90°, 180°, 270°
• Aspect ratio correction
• Mirroring of images
• Text overlay
• Privacy mask
• Deinterlace filter
Pan/Tilt/Zoom • Wide range of analog PTZ cameras supported (drivers available for download at www.axis.com)
• 20 presets, guard tour, PTZ control queue
• Supports Windows compatible joysticks
Users 20 simultaneous viewers
Security Password protection, IP address filtering, HTTPS encryption, digest authentication, user access
log
Supported protocols • IPv4/v6, HTTP, HTTPS, QoS layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II),
DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, etc.
• SSL/TLS*
*This product includes software developed by the Open SSL Project for use in the Open SSL Tool
kit (www.openssl.org)
Application
Programming
Interface
• Open API for software integration, including VAPIX® from Axis Communications*, AXIS Media
Control SDK*, event trigger data in video stream
• Quality of Service (QoS) layer 3, DiffServ Model
• Embedded Linux operating system
• ONVIF, specifications available at www.onvif.org
*Available at www.axis.com
Alarm triggers Video motion detection
Alarm events • File upload via FTP, HTTP and email
• Notification via email, HTTP and TCP
• PTZ presets
Video buffer 20 MB pre- and post-alarm
Video access from web
browser
• Camera live view
• Video recording to file (ASF)
• Customizable HTML pages
• Windows 7, Windows XP, 2000, 2003 server
• DirectX 9c or higher
• For other operating systems and browsers see www.axis.com/techsup
Processor and memory ARTPEC-3, 64 MB RAM, 128 MB Flash
Power Power over Ethernet IEEE 802.3af Class 2
Connectors • Analog composite video BNC input, NTSC/PAL auto-sensing
• RJ-45 10BaseT/100BaseTX PoE
• 2.5 mm analog composite video tele plug input
• RS-485/ RS-422

Axis M7001 Specifications

General

Cable length	1.5 m

Weight and Dimensions

Weight	82 g
Dimensions (WxDxH)	37.4 x 101 x 30.1 mm
