Axis P1354-E - Connection Diagrams; Install the Hardware; Install the Wall Bracket

AXISP13-ESeries
ConnectionDiagrams
I/OConnector
1
2
3
4
1
0VDC(-)
2
DCoutput3.3V,max50mA
3
Digitalinput0tomax40VDC
4
Digitaloutput0tomax40VDC,opendrain,100mA
InstalltheHardware
InstalltheWallBracket
NO NO
NO
TICE TICE
TICE
•Theweightofthecamerais3000g(6.6lb).Checkthatthematerialisstrongenoughto
supportthisweight.
•Alwaysuseashieldednetworkcable(STP)intendedforoutdoorusebetweenthe
Axisproductandtheendpointandensurethattheendpointisproperlygrounded.
InstallationsofAxisproductsusingashieldednetworkcable(STP)andaproperly
groundedendpointhavebeentestedtocomplywithindustryimmunitystandardlevels
suchassurgeprotection.Anyotherinstallationmethodwillvoidthewarrantyand
leavetheunitatarisk.
18
