AXISP13-ESeries
Theproductcanbeusedwithmostoperatingsystemsandbrowsers.Therecommendedbrowsersare
•InternetExplorer
®
withWindows
®
•Safari
®
withOSX
®
•Chrome
TM
orFirefox
®
withotheroperatingsystems.
Formoreinformationaboutusingtheproduct,seetheUserManualavailableatwww.axis.com
AdjustFocus
Toadjustthezoomandfocusfollowtheseinstructions:
Note
•SetthefocusaspreciseaspossiblewiththefocuspullerorFocusAssistantbeforestarting
automaticnetuning.Usingthefocuspullernormallygivesthebestresult.
•Theirisshouldalwaysbeopenedtoitsmaximumwhilefocusing.Thisgivesthesmallest
depthofeldandthusthebestconditionsforcorrectfocusing.
1.Opentheproduct’shomepageandgotoSetup>BasicSetup>Focus.
2.UndertheBasictab,clickOpeniris.Ifthebuttonisinactivetheirisisalreadyopen.
3.Iffocushasbeensetbefore,clickResettoresetthebackfocus.
4.Loosenthezoomandfocuspullers(seeHardwareOverviewonpage10)onthelensby
turningthemcounter-clockwise.Movethepullerstosetzoomandfocusandcheckthe
qualityoftheimageintheimagewindow.
Ifthecameraismountedsothatonecannotlookattheimageandmovethepullers
atthesametime,usetheFocusAssistantinstead.See.
5.Loosenthezoompullerandthelockscrewforthefocusring(seeHardwareOverviewon
page10)onthelensbyturningthemcounter-clockwise.Movethezoompullerandthe
focusringtosetzoomandfocusandcheckthequalityoftheimageintheimagewindow.
Ifthecameraismountedsothatyoucannotlookattheimageandmovethezoompuller
andthefocusringatthesametime,usetheFocusAssistantinstead.See.
6.Re-tightenthezoomandfocuspullers.
7.OntheFocuspage,clickFine-tunefocusautomaticallyandwaituntilautomaticne
tuningiscompleted.
8.ClickEnableiris.Ifthebuttonisinactivetheirisisalreadyenabled.
9.Ifneeded,makefurtheradjustmentsundertheAdvancedtab.Seetheonlinehelpfor
moreinformation.
FocusAssistant
TofocususingtheFocusAssistant,followtheinstructionsinsteps1–3onpage23beforeyou
startwiththestepsbelow.
