Axis P3384-V Installation Guide

AXISP33/-VSeriesFixedDomeNetworkCamera
2.Routeandconnectallrequiredcables.Theseincludethenetworkcableandmayinclude
externalinput/outputdevicesandtheactivespeaker/externalmicrophone.
3.Attachthecameraunittothewallusingscrewsandplugsappropriateforthewall
material.
1
2
1
1
Wallscrews
2
Networkcable
MounttheCameraUsingaMountingBracket(notincluded)
Note
Themountingbracketcanalsobeusedformountingthenetworkcameratoajunctionbox.
1.Drilltwoholesinthewallusingthedrilltemplate.
2.Routethenetworkcableand,ifrequired,theI/Oandaudiocablesthroughthewalland
throughtheholesinthemountingbracket.
3.Attachthemountingbrackettothewallusingtwoscrewsandplugsappropriatefor
thewallmaterial.
4.Connectthecablestothecameraunit.
5.InserttheSDmemorycard(optional).
6.Attachthecameraunittothemountingbracketusingtwoscrews(notincluded).
18
