AXISP55NetworkCameraSeries
FunctionPinNotes
Specications
0VDC(-)
1
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspower
out.
3.3VDC
Maxload=
250mA
Digitalinput–Connecttopin1to
activate,orleaveoating(unconnected)
todeactivate.
0tomax40VDC
Congurable
(Inputor
Output)
3–6
Digitaloutput–Connectedtopin1when
activated,oating(unconnected)when
deactivated.Ifusedwithaninductive
load,e.g.arelay,adiodemustbe
connectedinparallelwiththeload,for
protectionagainstvoltagetransients.
0tomax40VDC,
opendrain,
100mA
Foranexamplediagram,seeConnectionDiagramsonpage15.
I/Oconnector
1 2 3 4 5 6
DCpowerinputACpowerinput
14
