AXISP55NetworkCameraSeries
PowerConsumption
NO NO
NO
TICE TICE
TICE
Usealimitedpowersource(LPS)witheitheraratedoutputpowerlimitedto≤100W
oraratedoutputcurrentlimitedto≤5A.
PoE
ACDC
PoweroverEthernet(PoE)
IEEE802.3af/802.3at
Type1Class3max.12.95W
20-28VDC,max.22VA20-24VAC,max13.5W
InstalltheHardware
NO NO
NO
TICE TICE
TICE
Mounttheproductwiththedomefacingdownward.
Readalltheinstructionsbeforepreparingtoinstallthenetworkcamerasinceseveralinstallation
preparationstepsrequireremovingthetopcoverandwouldbenetfrombeingcompletedtogether.
•Removetheprotectivepackagingbeforeinstallingthecamera.
•Theproductissuppliedwithacleartransparentdomecover(premounted)andasmoked
transparentdomecover.Toreplacethedomecover,seepage17.
•AstandardorhighcapacitySDcard(notincluded)canbeusedtostorerecordings
locallyintheproduct.Seepage17.
•ToinstalltheproductusingacompatiblebracketfromAXIST91AMountingAccessories
(soldseparately),seepage20.
RemovetheProtectivePackaging
SeeHardwareOverviewonpage9forlocationofcomponents.
1.Loosenthefourtopcoverscrewsandremovethetopcover.
2.Removetheprotectivepackaging.
16
